IHC Tumor Vascularization
Segment tissue into tumor and healthy/stromal regions, detect blood vessels (e.g., CD31), and quantify vessel number, area, density, and connectivity within each compartment.
blood vessels, tumor vascularization, tumor microenvironment, CD31, pancreas
The IHC Tumor Vascularization APP provides tissue detection including the separation into tumor tissue and healthy tissue (or tumor stroma). It additionally detects blood vessels based on appropriate stains (e.g. CD31) and measures number and area of the blood vessels. The vessel detection also can be set to close open stained vessel walls and to connect separated vessel sections within a definable distance. The APP outputs number and vessel density as well as areas of vessels, within tumor tissue and healthy tissue.
Dr. Patrick Michl, Dr. Maren Egidi and Dr. Heidi Griesmann, Universitätsklinikum Halle (Saale).
Original Image
Tumor detection
Vessel detection
Combined detection
Application Note
01 Jun, 2023
Evaluating the Distance of Tumor Cells from Blood Vessels
White Paper
17 Oct, 2025
Integrative Multiomics Approach Unveils Systemic Dysfunction in Colorectal Cancer (CRC)
Blog Post
17 May, 2023
An Intro to Deep Learning in Biomedical Imaging
We support the following file formats:
- TissueFAXS (aqproj)
- StrataFAXS II (vmic)
- PreciPoint (vmic, gtif)
- Generic BigTIFF Import
- Support for multipage BigTIFF files
- OME-TIFF
- JPEG, PNG, BMP, TIFF
- Zeiss (czi)
- Hamamatsu NanoZoomer (ndpi)
- Aperio (svs)
- Leica (scn)
- 3D HISTECH Pannoramic
- Mirax (mrxs)
- Olympus (vsi)
- More slide scanners to be added!
